Procedural Content Generation using Perlin Noise (among others)

Computing Club (03/03/2026)

Erik Fredericks, frederer@gvsu.edu
Winter 2026

https://efredericks.github.io

(Background image: Etienne Jacob)

But first, how do we make a game map?

(and, what does the data structure look like?)

Any reason for not doing it by hand?

Procedural Content Generation (PCG)

What is PCG?

• Algorithmically-placing content!

Why is PCG?

• Save the developer/designer time and effort!
  • One would think...

Why bother talking about this?

• I recently sent out a paper on it and thought you might find it interesting
• Plus, useful for gamejam things

Basic concept

Use math/algorithms to place content intelligently

• Dungeons, items, etc.

Noise functions:

• Calculate a noise value based on inputs and configurations
• Your job is to map that value to something useful

For example - Perlin noise

Typically, returns a value in [-1.0, 1.0], though p5js uses [0.0, 1.0]

For example (in p5):
let n = noise(x * 0.01, y * 0.01);

• n = [0.0, 0.5] -- (x, y) -> water
• n = (0.5, 0.6] -- (x, y) -> beach
• n = (0.6, 0.9] -- (x, y) -> grass
• n = (0.9, 1.0] -- (x, y) -> rock

You do effectively the same in any language/editor!

There are other noise functions! Worley noise, Simplex noise, etc.

How does noise generate this?

Demo time

This time I made a pre-baked p5js template for you. Go to this link and File -> Duplicate

• Make sure you login and save often

The sketch

• You should have a little ASCII happy face that you can move around with your arrow keys
• Your game map is represented as a two-dimensional grid where the first index is the row and the second index is the column
• There is also a basic camera that follows your player so that we can make big maps

The map

[['#', '#', '#', ..., '#'],
 ['#', ' ', ' ', ..., '#'],
 ['#', '.', 't', ..., '#'],
 [...],
 ['#', '#', '#', ..., '#']]

game_map[2][1] returns a ???

• .

By default, the map puts walls on the outside and nothing on the inside - your job is to fill it with things

Valid things:

Try setting some random cells to these characters!

• such as, game_map[2][3] = 'g'; in setup() AFTER the game map is created

First, let's randomize things

After the call to setupGameMap() (which again, just gives us an empty grid with borders)

for (let r = 1; r < num_rows - 1; r++) {
  for (let c = 1; c < num_cols - 1; c++) {
    let r = random();
    let ch = ' ';
    if (r > 0.8) ch = '#';

    game_map[r][c] = ch;
  }
}

Now let's give it a bit of detail

First, comment out what you did inside that double loop.

const zoom = 0.01;
for (let r = 1; r < num_rows - 1; r++) {
  for (let c = 1; c < num_cols - 1; c++) {
    let ch = ' ';
    let n = noise(c * zoom, r * zoom);


    // fill in with code from next slide


    game_map[r][c] = ch;
  }
}

The noise bit

if (n <= 0.5) ch = 'w';
else if (n <= 0.6) ch = 'b';
else if (n <= 0.9) ch = 't';
else {
  let r = random();
  if (r > 0.8) ch = '.';
  else ch = ' ';
}

The finesse bit

Now this is the tricky part - you need to play with the zoom value and the noiseDetail (at the top) values to get exactly the output you want!

Try varying the:

• zoom into the noise distribution (try 0.1, 0.001, etc.)
• https://p5js.org/reference/p5/noiseDetail/
  • The number of octaves (first parameter in noiseDetail) - [1, 16] usually show interesting values
  • The falloff amount (second parameter in noiseDetail) - [0.0, 1.0]

Other ways to do it!

Use a different algorithm!

• Rectangular room placement
• Cellular automata
• Wave function collapse ->
• ...

There's a cellular automata implementation in the demo - instead of building your map in setup try calling game_map = CA();
